Industrial Handheld Non-Contact Ink Jet Printer

Industrial Handheld Non-Contact Ink Jet Printer

Product Code: EQUP-MC20087-0001

Categories: Bottle Filling and Batch Coding Machinery

982

Download PDF Enquire Now
  • Description

Industrial Handheld Non-Contact Ink Jet Printer



Specification

Model Type    Hand Held Inkjet Printer
Print Method    HP Cartridge
Capacity    500 pieces per minute
Automation Grade    Semi-Automatic
Condition    New
USB Available    Yes

Which is a 4-in-1 Compact design, Zero Maintenance, 300 dpi high resolution, Mains/ Battery Powered SIX line (character height 1.2 to 12.7 mm) Printer & can be used on Porous / Non-Porous products to print B.No., Exp.Date, Time, Serial No., Logos, Scannable Bar Codes, etc. on labels, cartons, pouches, drums, containers, etc. It is fully programmable using the 4.3-inch full color Touch Screen LCD or with input from Pen Drive and is also capable of printing Multi-Segment / Grouped messages. It can also be mounted on stand for On-Line Printing.

Display

4.3” full color Touch Screen LCD with LED backlight.

Languages

English, Spanish, French, German, Chinese, etc.

Input Device

800 x 480 Touch Screen LCD, Pen Drive.

Printable Images

Alphanumeric, Logo, Date/Time, Counter, Barcode, etc. UPCA, UPCE, EAN13, EAN8, INT25, CODE39, CODE128, ENA128, PDF417, DATAMATRIX, QR

Printing Area

1 to 6 lines of 2000 characters from 1.2 to 12.7 mm high.

Printing Direction

Adjustable at any angle within 360 degree

Message Capacity

Store upto 999 messages with Message Name.

Printing Speed

Max. 70 meters/min for 1 to 6 line printing at 300 dpi

Prints Using

Hewlett-Packard (hp) TIJ 2.5 Print-head for spraying ink

Print Distance

Max. 6 mm from substrate down or in front.

Inking Medium

42 cc disposable pre-mix ink in Cartridge form with head.

Printing Medium

Solvent/Oil based inks (black, white, red, blue, yellow, etc.)

Ink Drying Time

Min. 5 seconds on plastics & laminates.

Impressions

Appx. 25 Lakh characters of 2 mm per cartridge of ink.

Operating Range

10 ~ +38ºC 10% - 80% RH, non-condensing.

Supply Voltage

90 - 240 Vac, 50/60 Hz, 5 W

Battery Voltage

16.8V lithium battery, 10 hours use / 20 hours standby

Dimensions

H130 x W128 x D20 mm

Weight

1.2 Kg excluding cartridge & battery.

This printer is fully Electronic without CORE system & does not have any air pump, viscosity control unit, filters, etc. & so there is no maintenance required (No AMC). It does not require separate make up or wash solution as everything is included in the disposable ink cartridges making it very user friendly for the Operator. The running / Printing cost is only about 4 Paise per impression (25 char).
