Product
Description
Inkjet Batch Coding Printer
Technical specification
Paper Size A1
Weight 15 kg.
Voltage 230 V
Automatic Paper Sensor Automatic
Color Output Colored,Monochrome
Condition New
Item Colour Black,White,Gray
These coders are ideal for On-Line High Speed Coding on packaging machines or bottles moving on conveyor.
The message to be printed is very easily composed on its graphic display using the integrated complete The message can be upto 4 lines with a combination of small, medium or large characters from 1 mm to 17 mm in height along with LOGOs.
The Inking system consists of a simple disposable pre-mix ink cartridge using fast drying & indelible solvent-based inks (for porous and non-porous surfaces) which is just push fitted into its SLOT & immediately you can start printing.
The small print head is then placed aligned with the object or substrate & whenever the product sensor gives a signal, the whole message is spray-printed onto the substrate while it is in motion without touching it.
|
Supply Voltage |
230 Vac ± 10%, 50 VA |
|
Operating Range |
5 to 45 deg. C, 10 – 90% RH non-condensing. |
|
Printing Area |
4 lines of 120 char each from 1 to 17 mm high. |
|
Printing Speed |
Max. 50 Meters / min. for 1 to 4 line printing. |
|
Prints using |
Piezo-electric print head for spraying ink. |
|
Inking Medium |
Disposable pre-mix ink in 200 ml. cartridge |
|
Printing Medium |
Solvent based inks (black, white, yellow, etc.) |
|
Impressions |
Appx. 90 million char. of 2 mm per lit. of ink. |
|
Dimensions |
20X30X36 cm & 31X38X100 cm with stand. |
|
Weight |
15 Kgs for machine & 30 Kgs with stand |
Bulk manufacturing
Bulk manufacturers of Inkjet Batch Coding Printer in China
Bulk production of Inkjet Batch Coding Printer runs on our own lines in China, quoted factory-direct so the unit price falls as the quantity rises instead of sitting at a fixed list price. Wholesale buyers and project contractors sourcing inkjet batch coding printer from China usually begin with a quantity and a required delivery date, and that is all we need to return unit cost at volume, crate dimensions, gross weight and container fill. If you are comparing quotations from several suppliers, ask each of them to state the make of the major components: on this class of machine that is where real cost differences hide, not in the headline figure.
OEM and ODM production is available on bulk quantities of inkjet batch coding printer, which for most buyers means voltage and frequency matched to the destination, a capacity that fits the line it is going into, contact parts specified for the material being handled, and branding, manuals and cartons in your own name. Plan on three to six weeks in production for a made-to-order build plus transit, or seven to ten working days where the item is in stock.
If you are still narrowing down the specification, the wider strapping and sealing machine range is worth comparing before you send the enquiry.
- Factory-direct pricingUnit cost banded by quantity, held for the validity period on the quotation.
- OEM and private labelBrand plate, manual and carton artwork in your own name on volume orders.
- Built to specificationVoltage, phase, frequency, capacity and contact materials set for your market.
- Inspection before dispatchIn-process checks plus a photographed pre-dispatch report for your approval.
- Container planningWe confirm the fill for a 20ft, 40ft or 40ft high-cube before you commit.
- Repeat ordersBuild specification kept on file so a second order is quoted against the same machine.
Export and shipping
Importing Inkjet Batch Coding Printer from China
The documents matter as much as the machine when you are importing inkjet batch coding printer from China. HS classification is settled at quotation stage, and the consignment ships with a commercial invoice, packing list and certificate of origin, plus a fumigation certificate and marine insurance where your customs authority asks for them. Pricing is quoted FOB from the port of loading if you are using your own forwarder, or CIF to a named destination port if you want freight handled at our end.
Crating is built for the voyage rather than for a shelf, with moisture protection and shock resistance matched to the sea time to your port. If you are buying several ranges at once they can travel as one consolidated consignment on a single bill of lading, which reduces both the cost per unit and the number of documents to clear. Every machine ships with installation drawings, an operating manual and a spare parts list.
- HS classificationSettled before the quotation is issued, not at your port.
- Document setInvoice, packing list, certificate of origin, fumigation certificate, insurance.
- FOB or CIFYour forwarder from the loading port, or ours to your named destination port.
- Seaworthy packingCrating and moisture protection sized for the sea time to your market.
- Consolidated shippingSeveral ranges combined onto one bill of lading.
- After deliveryInstallation drawings, manuals and a spare parts list with every machine.
Buyer questions
Inkjet Batch Coding Printer — frequently asked
Anything not covered here, put it in your enquiry and we will answer it with the quotation.
Email the sales deskWhat is the minimum order quantity for Inkjet Batch Coding Printer?
inkjet batch coding printer can be supplied as a single unit where it is capital machinery, with banded pricing once the order runs to several units. Hand tools, spares and consumables are quoted in batch or container quantities instead. Tell us the quantity and the delivery window and we will confirm which minimum applies.
Can Inkjet Batch Coding Printer be manufactured to our own specification?
Yes — OEM and ODM production is standard on bulk orders. The usual changes are voltage and frequency for the destination, capacity to suit the line it feeds, contact parts specified for the material being handled, and your own branding on the machine and packaging.
What is the production lead time for a bulk order?
Made-to-order machines typically take three to six weeks in production, plus sea freight transit to your port. Ready-stock items dispatch within seven to ten working days. Exact lead time is confirmed in writing on the quotation.
Can we inspect the goods before shipment?
Yes. Every consignment goes through in-process checks and a pre-dispatch inspection, and the photographed report is shared for your approval before the container is sealed. Third-party inspection by SGS, Bureau Veritas or an agency you nominate can be built into the terms.
What are your payment and shipping terms?
Terms are set on the proforma invoice and depend on order value and destination. Advance payment by telegraphic transfer against a proforma invoice is standard, and irrevocable letters of credit are accepted on larger capital orders. Shipping is quoted FOB from the port of loading or CIF to a named destination port.
Do you supply spare parts and documentation?
Installation drawings, an operating manual and a spare parts list are issued with every machine. Spares can be ordered against the original build specification, which we keep on file, and for plant-scale orders commissioning support can be arranged at quotation stage.
